Inductive AC Circuit Simulation
Visualizing the relationship between voltage and current in an inductive circuit
Circuit Parameters
Inductance (L)
44 mH
Frequency (f)
50 Hz
Voltage (V)
220 V
Current Waveform
Phase Shift
90°
XL = 2πfL = ωL
IRMS = VRMS / XL
Inductive Reactance (XL):
13.82 Ω
RMS Current (IRMS):
15.92 A
Angular Frequency (ω):
314.16 rad/s
